The Nobilia Maxi diagonal corner cabinet UE90-45-M (65×65 cm, 86.4 cm): 1 door | 1 drawer | 1 shelf | corner filler piece – for the kitchen corner, complete corner utilization.

Technical data:
• Carcass dimensions: 90×45 cm | Carcass height: 86.4 cm
• Planning dimensions: standard 65×110 cm (flexible 63–75 × 108–120 cm)
• Side depth: 56.1 cm
• Configuration: 1 door | 1 drawer | 1 shelf | corner filler piece
• SoftStoppPro | Sensys hinge | 5-year warranty | Made in Germany | factory-assembled

Nobilia corner cabinet with shelf: shelf freely adjustable in a 32 mm grid – custom compartment layout for pots, bowls and pantry items. 5-year Nobilia manufacturer warranty. Made in Germany. Factory-assembled. Side depth 56.1 cm. SoftStoppPro as standard. As a Nobilia-certified specialist retailer since 2015: direct delivery from the factory, free shipping, approx. 3–4 weeks. Personal contact in Frankfurt.

Scope of delivery:
• Factory-assembled – set it in place and you're done.
• Nobilia installation material is included.
• Plinth package at no extra charge: front panel min. 220 cm + side panel 110 cm + connectors.
• Plinth height 2, 7, 10, 15 or 20 cm | Delivery time approx. 3–4 weeks | free shipping.

For over a decade, we have delivered direct from the factory as a Nobilia-certified specialist retailer. Free shipping, approx. 3–4 weeks. Personal contact in Frankfurt am Main.

Footprint half-corner: door width × carcass width (asymmetric) When planning a kitchen with UE90-45-M: carcass dimensions 90×45 cm (carcass 90 cm, door 45 cm). Planning dimensions from the corner: standard 65×110 cm, variation range 63–75 × 108–120 cm. Corner filler piece 70×70 mm standard.
